Description
? True RMS measurement
? For measuring solar, PV systems
? Auto ranging
? Bar-graph indication
? Data hold function
Ϡ3000V DC Voltage measurement
Ϡ2000V AC Voltage measurement
ϠAC mA/uA measurement
ϠDC mA/uA measurement
? Low battery indication
? Auto power off
? Low power consumption
ϠRugged and compact
? Comply with
IEC / EN 61010-1, CAT III 1000V
IEC / EN 61010-1, CAT IV 600V
? Comply with CAT III 1000V for the
range of 0~1000V AC/DC
| DC Voltage | |||
| Ranges | Resolution | Accuracy | |
| 400mV | 0.1mV | ±(0.5%rdg+5dgt) | |
| 4V | 1mV | ||
| 40V | 10mV | ||
| 400V | 100mV | ||
| 1000V for CE | 1V | ||
| 3000 for general | 1V | ±(1.0%rdg+3dgt) | |
| ․Input impedance : 10MΩ | |||
| AC Voltage | |||
| Ranges | Resolution | Accuracy | |
| 400mV | 0.1mV | ±(1.0%rdg+5dgt) | |
| 4V | 1mV | ||
| 40V | 10mV | ||
| 400V | 100mV | ||
| 1000V for CE | 1V | ||
| 2000 for general | 1V | ±(1.5%rdg+3dgt) | |
| ․Input impedance : 10MΩ | |||
| DC mA / µA | |||
| Ranges | Resolution | Accuracy | |
| 400µA | 0.1μA | ±(1.2%rdg+5dgt) | |
| 4000µA | 1μA | ||
| 40mA | 0.01mA | ||
| 400mA | 0.1mA | ||
| ․Overload Protection 0.5A/1000V fast blow fuse for 400mA | |||
| AC mA / µA | |||
| Ranges | Resolution | Accuracy | |
| 400µA | 0.1μA | ±(1.5%rdg+3dgt) | |
| 4000µA | 1μA | ||
| 40mA | 0.01mA | ||
| 400mA | 0.1mA | ||
| ․Overload Protection 0.5A/1000V fast blow fuse for 400mA | |||
| GENERAL | |||
| Dimensions | 221mm(L) x 110mm(W) x 57mm(D) | ||
| Weight (battery included) |
Approx. 507g | ||
| Power source | 1.5V (AA) Alkaline battery x 2 | ||
| Safety standard | IEC / EN 61010-1 CAT III 1000V IEC / EN 61010-1 CAT IV 600V EN 61326-1 |
||
