Description
Timed IR plus PI and DAR diagnostic tests
Operates with a dead battery when online power/mains
Rapid charge Li-ion battery: Up to 6 hours continuous testing (5kV)
Dedicated voltmeter function (30V to 660V)
Large LCD display with an automatic backlight
Noise filter – Rejects up to 3mA noise
High altitude operation up to 3000m
| Attribute | Value |
| Tester Type | Insulation Tester |
| Minimum Test Voltage | 500V |
| Maximum Test Voltage | 10000V |
| Maximum Insulation Resistance Measurement | 20TΩ |
| Display Type | LCD |
| Test Current | 6mA |
| Battery Life | 4.5 h |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +50°C |
| Power Source | Battery, Mains |
| Safety Category | CAT IV 600V |
| Model Number p | MIT1025 |
| Height | 181mm |
| Length | 315mm |
| Width | 285mm |
| Battery Type | Li-ion |
| Dimensions | 315 x 285 x 181mm |
| Plug Type | Type C – European Plug, Type G – British 3-pin |
| Weight | 4.5kg |
